10.0V 50W Zener Diode, Reverse Polarity Stud Mount

Stud Mount Zener Diode for Precision Voltage Regulation

This 10.0V 50W zener diode is engineered for reliable voltage regulation and overvoltage protection in demanding power supply circuits. Featuring a robust stud mount (DO-5 package) design, this zener diode offers outstanding stability and thermal performance, making it ideal for high-power industrial and commercial applications.

Key Features and Specifications

• Nominal Regulating Voltage (Vz): 10.0 Volts
• Power Dissipation: 50 Watts
• Mounting: Stud Mount (DO-5 Package), Reverse Polarity
• Configuration: Cathode-to-Case
• Quantity Per Package: 1

Applications

This zener diode is designed for use in power regulation, voltage reference, and overvoltage protection circuits. Its high wattage capability and precise voltage control make it suitable for industrial, instrumentation, and power management systems requiring dependable regulation under continuous load.

Technical Notes

• Ensure proper heatsinking via the stud mount to maintain optimal performance.
• Reverse polarity configuration for versatile installation options.
• Compatible with a wide range of power supply and voltage stabilization applications.

Part Number: NTE5252AK

This part is the equivalent replacement for the following:

1N3309AR, 1N3309BR, 1N3309R, 1N3309RA, 1N3309RB, 50T10R, 50T10RA, 50T10RB, BZY93C10 (Minor mechanical difference exists, but device will fit most applications.), ECG5252AK, ECG5252K, HZ50V10R, IN-3309R, NTE5252AK, SK535, SK535/5252AK, TM5252AK, WEP3309R Vetco stocks a complete inventory of electronic parts, including Integrated Circuits (IC’s), Transistors, Diodes, and LEDs. Looking for more information? Please click here to search NTE’s online component CROSS REFERENCE SEARCH
