100V 0.5W Zener Diode DO-35 Axial Lead

Reliable Voltage Regulation with the NTE5050A Zener Diode

The NTE5050A 100V 0.5W Zener Diode is designed for reliable and precise voltage regulation in a broad range of electronic applications. With its nominal regulating voltage of 100 volts and power rating of 0.5 watts, this Zener diode is ideal for voltage reference, voltage clamping, and overvoltage protection in circuit designs that demand stable operation.

Technical Specifications

• Nominal Zener Voltage: 100V
• Power Dissipation: 0.5W (1/2W)
• Diode Type: Zener (Silicon)
• Lead Type: Axial (DO-35 Package)
• Manufacturer Part Number: NTE5050A
• Quantity per Package: 1

Features and Benefits

• Consistent voltage regulation with 100V nominal Zener voltage
• Through-hole DO-35 package suited for high-density PCB layouts
• Axial lead form factor for easy integration and secure soldering
• 0.5W power rating supports a wide array of general purpose and industrial applications
• Suitable for protecting sensitive components from voltage transients

Applications

• Voltage regulation in power supply circuits
• Voltage reference for analog and digital systems
• Overvoltage protection for electronic components
• Signal conditioning and clamping applications

Usage Instructions

Install the NTE5050A Zener Diode in the desired location on your PCB using standard through-hole practices. Observe correct polarity: connect the cathode to the higher voltage potential for voltage regulation or clamping. For optimal thermal performance, ensure the ambient temperature supports adequate heat dissipation within the 0.5W rating.

This part is the equivalent replacement for the following:

1/2Z100T5, 13-0033187-002, 13-33187-2, 1/4A100, 1/4A100A, 1/4A100B, 1/4M100Z, 1/4M100Z10, 1/4M100Z5, 1/4Z100D, 1/4Z100D10, 1/4Z100D5, 157-101(MAG-ZENER), 187-2(SYL), 1902-0793, 1N1944, 1N1944A, 1N1971, 1N1998, 1N1998A, 1N3428, 1N5271, 1N5271A, 1N5271B, 1N5887, 1N5887A, 1N5887B, 1N6024A, 1N6024B, 1N671, 1N738, 1N738A, 1N738B, 1N985, 1N985A, 1N985B, 1S2575, 254-2(MAG-ZENER), .25N100, .25T100B, 4822-130-31005, 482213031005, 48-83827D09, .4M100Z, .4M100Z5, 530157-101, 5302541002, 530254-2, .5M100ZS10, .5M100ZS5, 9334-291-20112, 933429120112, BZX55C100, ECG5050, ECG5050A, HM100, HM100A, MZ500-40, NTE5050A, RD100EA, SK100A, SK100A/5050A, SK3816, SK3816/5050A, TM5050A, WEP1456
